  SeTAC - Total vibration control onboard machine tools

  SeTAC (SEQUOIA Triaxial Acceleration Computer) is a compact and complete device, installed onboard the machine, able to measure, analyze and store the most significant vibration phenomena of the machine tools. SeTAC is able to protect the machine, to improve the manufacturing process, to perform preventive maintenance activities and to store machine information as a black box.

  The SeTAC sensor is also able to communicate directly with numeric control adapting the machine performance to real time vibration status, and to provide by remote information the vibration history of the machine and the real time situation for diagnostic.

  Функции

  • Fast digital outputs with reaction time lower than 1 ms
  • Fieldbus (PROFIBUS, PROFINET or other) communication on board
  • Three axes digital accelerometer
  • No need of periodical calibration
  • Internal clock calendar and flash memory to catalog any alarms and vibration problem
  • Extremely robust and reliable: specifically designed for machine tool environment
  • Able to be connected by web thanks to Ethernet port both for black box checking and real time diagnostic
  • HMI for SINUMERIK CNC

  Интеграция

  SeTAC can be used for the following CNC:

  • SINUMERIK 840D sl
    with SINUMERIK PCU 50.5 Windows 7

  Особенности

  • Fast collision reaction and black box
  • Preventive maintenance planning
  • Improve your manufacturing process
  • Machine protection from excessive vibration, overloads, chattering and any unexpected vibration phenomena
  • Real time data and black box remotely available by Internet connection
